1PC 64MPa  M16-G1/4  Hydraulic Pressure Test Hose Female Liquid Hydraulic Test Hose Black End Gauge Connecting Cable

Descriptions:

Hydraulic test hose is used in the hydraulic system, test the pressure of each point in the hydraulic system and as a conduit for conducting fluid media. And has good performance of oil resistance, acid and alkali resistance, high pressure resistance.

Features:

  • Used in the hydraulic system, test the pressure of each point in the hydraulic system and as a conduit for conducting fluid media.
  • It has the features of advanced structure, reliable seal, strong attachment, light weight and easy to use.
  • Lining layer is nylon, the enhancement layer is extremely strong industrial fiber, outer cladding is made from polyurethane.
  • This hydraulic test hose has good performance of oil resistance, acid and alkali resistance, high pressure resistance.
  • One end is M16*2 female, connect to coupling; the other end is BSP1/4 female, connect to Gauge.

Specifications:

Color: black
Wall thickness: 1.5 mm
Temperature: - 40 ℃ to + 120 ℃
Lining: nylon
Enhanced layer: super industrial fiber
Outer cladding: polyurethane

Hose I.D.=2mm, O.D.=5mm

Allowable working pressure: 64Mpa
Minimum blasting pressure:160Mpa
Minimum bending radius: 30 mm/1.18inch

Weight:105g

Package Included:

1 x Hydraulic Pressure Test Hose
